In this case, close the “Room” dialog box by clicking “Cancel”. In copied projects or drawing files, layers of finish specifications might not correctly be listed in the “Room” dialog box. You can assign attributes to bar reinforcement without problems. If “Allplan Quality Manager” is turned on in “Allplan Diagnostics”, you get messages about the XML file of user-defined attributes saved in a project-specific manner. Properties” tool, you can separately change the properties of the second wall layer or of additional wall layers again. When you change the properties of individual wall layers by means of the “Change Archit. You can mirror certain curved dimension lines again. Label DimensionĪllplan correctly updates certain associative dimension lines after you have changed the thickness of a slab. You can draw and change pattern lines without problems.
You can place a PythonPart in a drawing file again after you have undone the creation of the PythonPart in another drawing file. You can freely define the height of the window handle for window SmartParts that open to the outside. User-defined objects, libraries SmartParts When you export layouts by using the “Export PDF Data” tool with the “Export layers” option being selected, the names of the layers will correctly be used for the levels in the PDF file again. DWG interfaceĪfter DWG export, drawing files whose names start with “*” appear correct in the layout area of the DWG file. We enhanced IFC export of general 3D objects.Īllplan correctly exports certain general 3D objects to IFC4, even if the “Support for freeform geometry” option is not selected in the “Advanced options” of the “IFC Export, Import Settings”. Teamwork Allplan ShareĪuto-save works correctly, even if a power-saving option is selected for the network adapter in conjunction with the “Automatically save drawing files and layouts” option (options - desktop environment). XRefsĪllplan correctly loads and processes certain XRefs, no longer displaying messages about the document size.
We solved this problem.Īllplan correctly exports loaded drawing files with resources, even if the drawing files contain formula attributes.
If the program stopped responding while saving drawing files, you might have not been able to select drawing files. Basic featuresĬertain tools such as “Delete” might not have functioned correctly when you selected a component by means of the Objects palette, sent this palette to the background by selecting another palette, and then canceled the selection of the component again. As a result, Allplan is more stable and reliable.Īllplan runs faster due to various means. We edited and corrected various messages of Quality Reporter.
